Name: A105 Round Steel Bar
SKU: 0

Home > Products > Carbon Steel > Carbon Steel Bar > A105 Round Steel Bar

A105 Round Steel Bar

A105 is an ASTM specification for steel forgings, primarily for carbon steel forged pipe components. The type of carbon steel wrought alloy involved is a low carbon, manganese and silicon steel similar to the AISI 1330, but with a lower manganese content.

+8618561841682

info@yufasteel.com

Contact Us

Products

Product Parameters

Carbon Steel: Properties, Production, Examples and Applications

Carbon steel is an iron-carbon alloy, which contains up to 2.1 wt.% carbon. For carbon steels, there is no minimum specified content of other alloying elements, however, they often contain manganese. The maximum manganese, silicon and copper content should be less than 1.65 wt.%, 0.6 wt.% and 0.6 wt.%, respectively.

Types of carbon steel and their properties

Carbon steel can be classified into three categories according to its carbon content: low-carbon steel (or mild-carbon steel), medium-carbon steel and high-carbon steel . Their carbon content, microstructure and properties compare as follows:

Carbon content (wt.%)	Microstructure	Properties	Examples
Low-carbon steel	< 0.25	Ferrite, pearlite	Low hardness and cost. High ductility, toughness, machinability and weldability
Medium-carbon steel	0.25 – 0.60	Martensite	Low hardenability, medium strength, ductility and toughness
High-carbon steel	0.60 – 1.25	Pearlite	High hardness, strength, low ductility

Carbon Steel Description

Grade:

1)GB: Q195, Q215, Q235A, Q235B, Q235C, Q235D, Q255A, 255B, Q275, Q295A, Q295B, Q345B, Q345C, Q345D, Q345E, Q390A, Q390B, Q390C,Q390D, Q390E, Q420, Q420B, Q420C, Q420D, Q420E, Q460D, Q460E, Q500D, Q500E, Q550D, Q550E, Q620D, Q620E, Q690D, Q690E

2)EN: S185,S235JR, S275JR, S355JR, S420NL, S460NL S500Q, S550Q, S620Q, S690Q

3)ASTM: Grade B, Grade C, Grade D, A36, Grade 36, Grade 40, Grade42, Grade 50, Grade 55, Grade 60, Grade 65, Grade 80

4)JIS: SS330, SPHC, SS400, SPFC, SPHD, SPHE

PRODUCT DETAILS

A105 Round Steel Bar Description

A105 steel bars are widely used in high temperature, high pressure and corrosive environments. This is because A105 has excellent mechanical properties and corrosion resistance. It has high strength and strength, can withstand high pressure and high temperature, and has good performance. In addition, A105 also has good processability and welding performance, making it easy to manufacture and repair. A105 can be used in chemical, petroleum, food and other industries. During the manufacturing process, A105 typically requires forging and heat treatment. Forging can change the internal structure of a metal and improve its mechanical properties. Heat treatment can change the surface structure and hardness of the metal, further improving its mechanical properties and corrosion resistance.

Product Parameters
Product Name	A105 Round Steel Bar
Standard	EN/DIN/JIS/ASTM/BS/ASME/AISI, etc.
Common Round Bar Specifications	3.0-50.8 mm, Over 50.8-300mm
Flat Steel Common Specifications	6.35x12.7mm, 6.35x25.4mm, 12.7x25.4mm
Hexagon Bar Common Specifications	AF5.8mm-17mm
Square Bar Common Specifications	AF2mm-14mm, AF6.35mm, 9.5mm, 12.7mm, 15.98mm, 19.0mm, 25.4mm
Length	1-6meters, Size Accept Custom
Diameter(mm)	Hot Rolling Round Bar	25-600	Cold Rolling Square Bar	6-50.8
	Hot Rolling Square Bar	21-54	Cold Rolling Hexagon Bar	9.5-65
	Cold Rolling Round bar	6-101.6	Forged Rebar	200-1000
Surface Process	Bright, Polished, Black
Other Services	Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.

Chemical Composition
Carbon Steel	C	Si	Mn	P	S	Cr
A105	0.35	0.10-0.35	0.60-1.05	0.035	0.04	0.3

Mechanical Properties
Tensile Strength (N/mm2)	Elongation %	Maximum Hardness HB
485	22	187

Scope of Application

A105 is used in trucks and marine components, railway vehicles, petrochemicals, milk mixers, engineering, general structural purposes, offshore and onshore services, etc.

Products

Product Display

Products ——

Product Packaging

Adopting a professional industrial packaging solution that is moisture-proof and scratch resistant, each batch of steel is tied and fixed with customized wooden frames/steel strips, combined with anti rust coatings and cushioning pads to ensure zero damage during transportation. Clear product model, batch number, and storage identification on the outer packaging, supporting customized enterprise logos and information labels. Environmentally friendly and recyclable packaging materials practice green concepts, reducing transportation and disassembly costs.

Products ——

Product Application

This product is widely used in the fields of building structures, mechanical manufacturing, automotive parts, energy equipment, and home hardware, and is suitable for scenarios such as load-bearing frames, precision parts, and industrial pipelines. With excellent physical performance and stability, it can easily meet the demands of high strength, high wear resistance, and extreme environments. Support collaboration with engineering teams to provide material selection suggestions and assist clients in efficiently implementing their projects.

Products

Factory Display

Products

Certificate

Products

FAQ

① Are you a trading company or a manufacturer ?

We are manufacturer. Every month, we do a procurement for a massive number of steel material from Chinese state owned mill. The total value of steel processing equipment is more than 30 million dollars. Our major products cover all category of steel industry, and it is totally compatible to all kind of world steel standard.

② Do you have large amount of steel products in stock ?

Yes, we do. In large-scale indoor warehouses, the total stock value is over 150 millions dollar.

③ Do you provide the samples ? Free or Extra ?

It is free, depend on the value of the sample. The cost of the freight would be charge.

④ How long is the delivery time ?

Officially, it is within 7 days. Actually, we can deliver within 3 days. Customized products or non-standard size products would be taken 10-30 days to deliver, depend on the production cycle. Generally, most of the products finished and delivered within 20 days.

⑤ Do you accept the third party inspection ?

Absolutely yes!

⑥ How could you guarantee your products ?

Each batch of products must have its own factory inspection report. If the third-party inspection report of the product you purchased does not match our factory inspection report, we will resend the goods, and we will carry all the costs by ourselves.

⑦ How can I get your quotation as soon as possible ?

You may have many methods to contact us. Email and fax will be checked within 12 hours, and Skype, WeChat and WhatsApp will be online in 24/7. Please send us your requirement, attaching specification (Steel grade, dimension, quantity, destination port) or any you are concerned, you will obtain a competitive price and supply solution soon.
